Specifications | |
Streaming | Chromecast Built-In, Apple Airplay, TIDAL, Spotify® Connect, Bluetooth (AptX HD), Internet Radio™, UPnP™ (hi-res streaming), Roon Ready |
USB | 2 x USB Type A Socket (front and rear) |
| External portable SSD – max. 1TB |
| USB sticks – max. 128 GB. |
Digital (S/PDIF) | 2 x Optical TOSLink (up to 24bit/96kHz) |
| 1 x Coaxial RCA (up to 24bit/192kHz, DoP 64Fs) |
| 1 x HDMI ARC (optional) |
Connectivity | |
Updates | Update your system wirelessly via the Naim app. |
Network | Ethernet (10/100Mbps), WiFi (802.11 b/g/n/ac with internal antennae) |
Formats | |
Internet Radio Formats | Windows Media-formatted content, MP3, ACC, OGG Vorbis streams and MMS |
Audio Formats | WAV - up to 32bits/384kHz |
| FLAC and AIFF - up to 24bit/384kHz |
| ALAC (Apple Lossless) - up to 24bit/384kHz |
| MP3 - up to 48kHz, 320kbit (16 bit) |
| AAC - up to 48kHz, 320kbit (16 bit) |
| OGG and WMA - up to 48kHz (16 bit) |
| DSD - 64 and 128Fs |
| Notes: Gapless playback supported on all formats. |
Physical | |
Dimensions | 95mm x 245mm x 265mm (HxWxD) |
Finishes | Brushed and anodised aluminium |
Weight | 7kg |
Power | |
Auto Standby time | User selectable: adjustable from off up to 2 hours |
Amplifier Output | 40W per channel into 8 ohms |
Mains Supply | 115V, 230V; 50 or 60Hz |
Power Consumption | Typical use: 90W |
| Network standby mode: <2W |
| Deep sleep: <0.5W |
| Network Standby (with SD Card and/or USB devices attached): > 15W*. |
| *Actual power consumption will vary depending on the size and type of attached SD card or USB devices |
Ripping and Storage | |
Storage | Store up to 20,000 tracks to a local USB connected storage device and serve to a network-connected player. |
| USB sticks – max. 128 GB. |
Supplied with | |
Supplied with | Remote control, Power-Line Lite mains cable (UK denominations only), cleaning cloth and quick start guide. |
Upgrades | |
Mains Cable | Power-Line mains cable |
Amplification | External power amplifier or sub-woofer |
User Control | |
App Control | Naim App for iOS and Android |
Front Panel | 5" colour TFT display and rotary volume control with proximity sensor and four buttons |
Handheld | zigbee RF4CE |
